LN1151
超低功耗 低跌落電壓 小電流電壓調整器
LN1151 系列是使用 CMOS 技術開發的超低功耗、低壓
差，高精度輸出電壓，正電壓型電壓穩壓器。由于內置有低
通態電阻晶體管，因而壓差低，能夠獲得較大的輸出電流。
為了使負載電流不超過輸出晶體管的電流容量，內置了
過流，短路等保護電路。
■ 產品概述
LN1151 系列是使用 CMOS 技術開發的超低功耗、低壓 差，高精度輸出電壓，正電壓型電壓穩壓器。由于內置有低 通態電阻晶體管，因而壓差低，能夠獲得較大的輸出電流。
為了使負載電流不超過輸出晶體管的電流容量，內置了 過流，短路等保護電路。
■ 產品特點
? 可選擇輸出電壓： 可以在 1.2～5.0V 的范圍內選擇,進 為 0.1 V
? 輸出電壓精度高： 精度可達±1.0%
? 輸入輸出壓差低： 典型值 200 mV (輸出為 3.0V 的產 品, IOUT=100mA 時)
? 消耗電流少：典型值 0.8μA
? 最大輸出電流：可輸出 250mA（VIN≥VOUT+1v）
? 待機電流：小于 0.1μA
? 內置保護：內置過流保護，短路保護
? 內置泄流管
■ 用途
? 可穿戴電子產品
? 安防
? 三表
? 實時時鐘
■ 封裝
? SOT-23-5L
? SOT23-3L
