XC6206
高紋波抑制率、低功耗、低壓差
XC6206系列是高紋波抑制率、低功耗、低壓差，具有過流和短路保護的CMOS降壓型電壓穩壓器。這些
器件具有很低的靜態偏置電流（6.0μA Typ.），它們能在輸入、輸出電壓差極小的情況下提供250mA的輸出
電流，并且仍能保持良好的調整率。由于輸入輸出間的電壓差很小和靜態偏置電流很小，這些器件特別適
用于希望延長電池壽命的電池供電類產品，如計算機、消費類產品和工業設備等。
■ 產品簡介
XC6206系列是高紋波抑制率、低功耗、低壓差，具有過流和短路保護的CMOS降壓型電壓穩壓器。這些 器件具有很低的靜態偏置電流（6.0μA Typ.），它們能在輸入、輸出電壓差極小的情況下提供250mA的輸出 電流，并且仍能保持良好的調整率。由于輸入輸出間的電壓差很小和靜態偏置電流很小，這些器件特別適 用于希望延長電池壽命的電池供電類產品，如計算機、消費類產品和工業設備等。
■ 產品特點
● 高精度輸出電壓：A檔:±1%，B檔: ±2.5%
● 輸出電壓：1.5V～5.0V(步長 0.1V)
● 極低的靜態偏置電流(Typ.=6.0μ A)
● 低的溫度調整系數
● 最高輸入電壓可達 8V
● 帶載能力強：當 Vin=4.3V 且 Vout=3.3V 時，Iout=250mA
● 可以作為調整器和參考電壓來使用
● 輸入穩定性好：Typ. 0.03%/V
● 封裝形式：SOT89-3、SOT23-3
■ 產品用途
● 電池供電系統
● 便攜式消費類設備
● 無繩電話設備
● 便攜式儀器
● 無線控制系統
● 汽車電子設備
● 便攜/手掌式計算機
● 電壓基準源
